510-R, Leaf removers for vineyards

Twenty years of experience in pneumatic leaf removers.

New air diffuser: greater performance, lower consumption

510-R

DESCRIPTION

Hind over row pneumatic deleafer, double row, 4 blowing heads (2x2), work on 2 complete rows, pendulum frame, self-centring guidance on the leaves wall, 6 hydraulic movements with electrohydraulic joystick, leaning wheels and skids, 30° frame tilting, cardan, hind 3 point hitching, with oil cooler kit. High operational yield.

TECHNICAL FEATURES

Min. required tractor power	100 HP
PTO	750 rpm
Weight	1000 Kg
Working speed	from 4 to 6 Km/h depending on the working conditions
PressioWorking pressure ne di lavoro	from 0,5 to 0,9 bar (adjustable with tractor’s PTO)

FUNCTIONING

The air produced by a compressor reaches the rotors, hits the leaves in the surrounding grape’s area in the whole deepness. A selective defoliation in the fruiting zone is obtained.

ADVANTAGES

The pneumatic deleafer Olmi, allows for optimal grape development, increasing quality, resulting in improved product health and quality wine.
It does not harm grapes during any period of use
Very short intervention times
POST-FLOWERING: Grape’s cleaning, removal of flowering residue, and all impurities on grape, it improves the penetration and efficacy of treatments, consequently reducing the amount of treatments with considerable costs savings. Improves ventilation within the grapes, preventing the formation of moisture that is harmful for the fruit development. Prevents from Botrytis. Early-stage leaves removal prevents from sun burning.
IN PRE-HARVEST: Facilitates manual harvesting with a saving of time of 30%, while with mechanical harvesting it eliminates moisture in the fruiting area and so a greater cleanliness of the crop can be reached, also fungicides and other impurities in the tanks of the harvesters can be reduced. Even in this phase the defoliator does not harm the grapes.

Accessories

PHOTO GALLERY
